Product Detail

51.2V

51.2V APS Series Lithium-ion Battery Module



Feature and Benefits

· Proven LiFePO4 chemistry, fire safety, and maximum cycle life for deep cycle and hybrid applications

· With Wi-Fi function, which supports remote fault diagnosis and the OTA upgrade function

· Integrated Smart Battery management system (BMS) with high energy density

· BMS technology ensures battery safety and reliability to avoid being overcharged and over-discharged, high current.

· Equalization and balancing of each cell prolong the battery life

· Intelligent monitoring, telemetry, remote communication, and control via RS485

· The capability of parallel connection of modules allows for increasing capacity

· LED indication for module status and alarms, fast charge capability, and Maintenance free

· 10 Years Warranty



Collect
Product Detail

Aeson Power APS series is a non-managed 51.2V LiFePO4 (Lithium-Iron Phosphate) battery module. With advanced LiFePO4 cell technology and smart BMS, the product has the benefits of long cycle life, small size, lightweight, high safety, and environmental protection. The battery has a Wi-Fi function, which supports remote fault diagnosis and the OTA upgrade function. It is well suited for solar battery systems, power backup systems, and energy storage applications.


Documents

51.2V 100Ah datasheet.pdf

51.2V Solar Battery Storage System.pdf



Specifications

Model

Battery Cell Technology

Voltage (V)

Capacity (Ah)

Max. Charge/ Discharge Current (A)

Dimensions (mm)

Weight (Kg)

Wi-Fi

Communication

APS5000

Lithium Iron Phosphate

51.2

100

100

442 * 470* 133

44

Available

RS485, CAN, RS232
